B
RIDGE
> C
ONFIG
> I
NTERFACES
(N
ETWORK
)
Configure the network interface bridging parameters from this menu.
B
RIDGE
> C
ONFIG
> I
NTERFACES
(NET) > S
UB
-I
NTERFACE
The network sub-interface is PPP [0.0] if the
L2
PROTOCOL
is set for
PPP
. The [0.0] represents the network
physical and logical ports respectively. This is a read-only field. The network sub-interface is
FRE [0.X]
if
the
L2
PROTOCOL
is set for
F
RAME
R
ELAY
. The [0.X] represents the network physical and logical ports
respectively. The network physical port is always 0. The X represents the Frame Relay logical port and
will be a number between 0-6 corresponding to the interface number under
L2 PROTOCOL > CONFIG >
DLCI MAPPING
. This is a read-only field.
B
RIDGE
> C
ONFIG
> I
NTERFACES
(ETH)
Configure the Ethernet Bridging parameters from this menu.
B
RIDGE
> C
ONFIG
> I
NTERFACES
(ETH) > S
UB
-I
NTERFACE
This is a read-only field which displays the physical and logical port of the interface using the following
nomenclature: [A.B], where A represents the physical port (network interface is 0, Ethernet is 1) and B
represents the logical port for the Layer 2 protocol (i.e. PVC for Frame Relay, PPP link, etc.) Each
configured logical port is assigned a number corresponding to the order in which they are listed in the L2
Protocol configuration fields.
B
RIDGE
> C
ONFIG
> B
RIDGE
T
ABLE
Configure the bridge table parameters from this menu.
B
RIDGE
> C
ONFIG
> B
RIDGE
T
ABLE
> B
RIDGE
T
ABLE
A
GING
(0-65535)
B
RIDGE
T
ABLE
A
GING
is how soon an entry ages out of the Bridge table (in minutes). Default is
5
.
B
RIDGE
> S
TATUS
View the bridging statistics from this menu.
B
RIDGE
> S
TATUS
> B
RIDGE
T
ABLE
View the bridge table status from this menu.
B
RIDGE
> S
TATUS
> B
RIDGE
T
ABLE
> MAC A
DDRESS
Ethernet address for device learned. This is a read-only field.
The ETH interface will not appear as a bridge interface entry if the mode is set to route IP.
