Section 4 User Interface Guide Total Access 600 Series System Manual
176 © 2004 ADTRAN, Inc. 61200624L1-1B
. 2. Configuring the Layer 2 Protocol
For more details on the configuration parameters discussed in this section, refer to the following pages:
Layer 2 ATM Network Interface Protocol menus beginning on page 101
Layer 2 Protocol (ATM) Configuration – T1 Interface
Step Action
1 From the main menu, select L2 P ROTOCOL and press NTER >.
2
Use the arrow keys to select the P ROTOCOL field for the T1 interface. Press
NTER >. Select ATM from the list of available protocols.
3
Use the arrow keys to select the C ONFIG menu for the T1 interface and press
NTER >.
4 Highlight the ATM C ONFIG menu for the T1 interface and press NTER >.
5 Enter the I DLE C ELLS format for your network.
6 Set D ATA S CRAMBLING appropriately for your network.
7
Back all the way out to one level to the PVC C ONFIG menu, and press NTER >.
Enter the VPI and VCI values for communicating with that Gateway. Select
R
OUTER under the C ONNECTION field.
8
Select the S ETUP menu and configure the virtual circuit for IP or PPP operation.
(Our example selects IP.) Refer to L2 Protocol (ATM–NET–ATM) > Config >
PVC Config > Setup (Router) on page 103 for more details.
9
Set mode to R OUTE IP. Using this menu you also have the option to route only
IP packets and bridge all other data packets (R OUTE IP/B RIDGE O THER ) or
bridge all data packets on this connection (B RIDGE A LL ). Refer to L2 Protocol
(ATM–NET–ATM) > Config > PVC Config > Setup (Router) on page 103 for
more details.
10 Left arrow back to the main menu to save the changes.
