Total Access 600 Series System Manual
Section 4 User Interface Guide
61200624L1-1B
© 2004 ADTRAN, Inc.
113
L2 P
ROTOCOL
(ATM–NET–C
U
MTN) > S
TATUS
> DLCI S
TATE
This is a read-only field that displays the live DLCI state.
L2 P
ROTOCOL
(ATM–NET–C
U
MTN) > S
TATUS
> P
ROTOCOL
S
TATUS
This is a read-only field that displays the live protocol status. Menu visible for physical and logical
V
OICE
ports only.
L2 P
ROTOCOL
(ATM–NET–C
U
MTN) > S
TATUS
> P
ROTOCOL
S
TATUS
> P
OTS
S
TATS
View the voice port activity and coding type.
L2 P
ROTOCOL
(ATM–NET–C
U
MTN) > S
TATUS
> P
ROTOCOL
S
TATUS
> C
LEAR
S
TATS
Clears all recorded statistics for the interface and returns all counters to 0.
L2 P
ROTOCOL
(ATM F
IRMWARE
) – V.35 I
NTERFACE
Configure the
L2 P
ROTOCOL
parameters and view the status of the V.35 interface using items from this
menu. The V.35 interface is only available when the configured network protocol is ATM. Refer to L2
Protocol (ATM Firmware) – NET> ATM on page 101.
L2 P
ROTOCOL
(ATM – V35) > P
ROTOCOL
Configure the
L2 P
ROTOCOL
mode. Choices are
FRF5
(def) and
FRF8
. Selecting
FRF5
configures the
interface for network interworking and should be used for Frame Relay over ATM applications. Selecting
FRF8
configures the interface for service interworking allowing the Total Access 600 Series to make the
translation between Frame Relay signaling on the V35 interface and ATM protocols on the network
interface.
L2 P
ROTOCOL
(ATM – V35) > C
ONFIG
Configures the
L2 P
ROTOCOL
parameters for either FRF5 or FRF8 signaling.
L2 P
ROTOCOL
(ATM – V35) > C
ONFIG
> UNI M
AINT
P
ROTOCOL
Specifies the maintenance protocol or signaling protocol between the local V.35 port and the attached DTE
port. The choices are
ANNEX D
(def),
ANNEX A
,
LMI
, and
STATIC
.
L2 P
ROTOCOL
(ATM – V35) > C
ONFIG
> UNI P
OLL
T
IMEOUT
T392 (5-30)
T392 for signaling protocol. This parameter has no meaning if the
UNI M
AINT
P
ROTOCOL
is set to
STATIC
(no signaling). The default setting is
10
.
L2 P
ROTOCOL
(ATM – V35)> S
TATUS
Displays the L2 statistics for FRF5 or FRF8 operation.
