eKINO-945GSE Motherboard
Page 75
5.8 Chassis Installation
5.8.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the eKINO-945GSE must have air
vents to allow cool air to move into the system and hot air to move out.
The eKINO-945GSE must be installed in a chassis with ventilation holes on the sides
allowing airflow to travel through the heat sink surface. In a system with an individual
power supply unit, the cooling fan of a power supply can also help generate airflow
through the board surface.
NOTE:
IEI has a wide range of backplanes available. Please contact your
eKINO-945GSE vendor, reseller or an IEI sales representative at
3
[email protected] or visit the IEI website (
3
http://www.ieiworld.com.tw )
to find out more about the available chassis.
5.8.2 Motherboard Installation
To install the eKINO-945GSE motherboard into the chassis please refer to the reference
material that came with the chassis.
5.9 Internal Peripheral Device Connections
The cables listed in
8
Table 5-10 are shipped with the eKINO-945GSE.
Quantity Type
1 Keyboard and Mouse cable
2 SATA drive cable
