eKINO-945GSE Motherboard

Page 6

Specification

eKINO-945GSE

Watchdog Timer

Software programmable 1-255 sec. through the iTE IT8718F

super I/O

Infrared

One infrared connector supports

Serial Infrared (SIR)

Amplitude Shift Keyed IR (ASKIR)

Power Supply

Recommended input voltage: 12-24 VDC

Maximum input voltage: 9-28 VDC

1 x External 4-pin DIN jack

1 x Internal 2x2 power connector

Power Consumption

1 A @ 12 V (with 1.0 GB DDR2 memory)

Temperature

With AUPS: 0ºC – 40ºC (32ºF – 104ºF)

Without AUPS: 0ºC – 60ºC (32ºF – 140ºF)

Humidity (operating)

5%~95% non-condensing

Dimensions (LxW)

170 mm x 170 mm

Weight (GW/NW)

1100 g / 370 g

Table 1-1: Technical Specifications
