eKINO-945GSE Motherboard

Page 71

5.7.2 Clear CMOS Jumper

Jumper Label:

J_CMOS1

Jumper Type:

3-pin header

Jumper Settings:

See

Table 5-3

Jumper Location:

See

Figure 5-4

If the eKINO-945GSE fails to boot due to improper BIOS settings, the clear CMOS jumper

clears the CMOS data and resets the system BIOS information. To do this, use the jumper

cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1

and 2.

If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault

may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the

following:

Enter the correct CMOS setting

Load Optimal Defaults

Load Failsafe Defaults.

After having done one of the above, save the changes and exit the CMOS Setup menu.

The clear CMOS jumper settings are shown in

Table 5-3.

Pin Setting

Description

1-2

Keep CMOS Setup

2-3

Clear CMOS Setup

Table 5-3: Clear CMOS Jumper Settings

5.7.3 CF Card Setup

Jumper Label:

J_CF1

Jumper Type:

2-pin header

Jumper Settings:

See Table 5-4

Jumper Location:

See Figure 5-4
