eKINO-945GSE Motherboard
Page 72
The CF Card Setup jumper sets the CF Type I card or CF Type II cards as either the slave
device or the master device. CF Card Setup jumper settings are shown in Table 5-4.
Pin Setting Description
Open Slave
Closed Master
Table 5-4: CF Card Setup Jumper Settings
5.7.4 COM3 RS-232/422/485 Selection Jumper
Jumper Label: JP1
Jumper Type: 6-pin header
Jumper Settings: See Table 5-5
Jumper Location: See Figure 5-4
The RS-232/422/485 Serial Port Select jumper sets the communication protocol used by
COM3. The RS-232/422/485 Serial Port Select settings are shown in Table 5-5.
Pin Setting Description
1-2 RS-232
3-4 RS-422
5-6 RS-485
Table 5-5: COM3 RS-232/422/485 Selection Jumper Pinouts
5.7.5 LCD Panel Type Selection
Jumper Label: J_LCD_TYPE1
Jumper Type: 8-pin header
Jumper Settings: See Table 5-7
Jumper Location: See Figure 5-4
The LCD Panel Type Selection jumper allows the LVDS screen voltage to be set. The
LCD Panel Type Selection jumper settings are shown in Table 5-7.
