eKINO-945GSE Motherboard
Page 5
1.2.3 Technical Specifications
eKINO-945GSE technical specifications are listed in
7
Table 1-1. See Chapter 2 for details.
Specification eKINO-945GSE
Form Factor Mini-ITX
System CPU 45 nm 1.60 GHz Intel® Atom™ N270
Front Side Bus (FSB) 533 MHz
System Chipset
Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7M
Memory
One 200-pin SO-DIMM socket supports one 533 MHz 2.0 GB
(max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® socket
Super I/O iTE IT8718F
Display
VGA
DVI (through Silicon Image Sil1362 on SDVO)
LVDS
HDTV
BIOS AMI BIOS label
Audio Realtek ALC655 AC'97 codec
LAN Two Realtek RTL8111C PCIe GbE controllers
COM
Three RS-232 serial ports (one internal, two external)
One RS-232/422/485 serial port (internal)
USB2.0 Six USB 2.0 devices supported (two internal, four external)
Hard Drives One 44-pin IDE connector
SATA Two 1.5 Gb/s SATA drives supported
Keyboard/mouse Internal pin header.
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the iTE IT8718F super I/O
