eKINO-945GSE Motherboard
Page 166
Check to disable the buzzer that warns when the system is switching to
use battery power.
Check to enable the LAN for remote monitoring function.
Check to enable the remote computer to turn the system power on or
off. (This function is not available at this stage)
Set the battery capacity parameter for the system to shut down automatically. In this case, the
system will shut down automatically when the battery capacity is below 5%.
Table 8-2: Status Settings
8.3 Remote Control and Monitoring
The eKINO-945GSE can be controlled (power on/off) and monitored the battery status
through a remote computer located in the same subnet with the eKINO-945GSE. To
control and monitor the eKINO-945GSE remotely, follow the steps below.
Step 8: Connect the remote control connector J11 to the LAN.
Step 9: In a remote computer, install the IEI REMOTE AP. Double click the setup.exe file
in the x:\Other\AUPS REMOTE AP directory. Follow the steps to install the IEI
REMOTE AP. After installation, launch the AP. If there is a problem to launch the
tool, execute the dotnetfxRedist20.exe first (located in the same directory of the
driver CD).
Step 10: The IEI REMOTE AP tool appears (Figure 8-16). All the eKINO-945GSE panel
PCs in the same subnet with this remote computer are shown in the list on the
right. Click the function buttons on the left to control the eKINO-945GSE.
