eKINO-945GSE Motherboard

Page 33

Connector

Type

Label

TV output connector

6-pin header

TV1

USB connector (2 ports)

8-pin header

USB1

Table 4-1: Peripheral Interface Connectors

4.1.3 External Interface Panel Connectors

8

Table 4-2 lists the rear panel connectors on the eKINO-945GSE. Detailed descriptions of

these connectors can be found in Section 1H4.3 on page

8

55.

Connector

Type

Label

Audio connector

Dual audio jack

AUDIO1

VGA/DVI combo connector

VGA and DVI connector

VIDEO1

LAN/USB combo connector

LAN and 2 x USB

LAN/USB1

LAN/USB2

Serial port connector

2 x DB-9 male

COM1 (top)

COM2 (bottom)

Table 4-2: Rear Panel Connectors

4.2 Internal Peripheral Connectors

Internal peripheral connectors are found on the motherboard and are only accessible

when the motherboard is outside of the chassis. This section has complete descriptions of

all the internal, peripheral connectors on the eKINO-945GSE.

4.2.1 BIOS Battery Connector

CN Label:

BT1

CN Type:

2-pin wafer (1x2)

CN Location:

See Figure 4-2

CN Pinouts:

See Table 4-3
