You see the Run screen.
Step 4 Click Browse.
You see the Browse screen.
Step 5 Select the a: drive.
Step 6 Click Setup.exe
Step 7 Click Open.
You return to the Run screen.
Step 8 Click OK.
The CATC USB Chief Install Wizard automatically installs the necessary files to
the computer’s hard drive. USB Chief software is installed in the c:\Program
Files\CATC\USB Chief directory unless you specify otherwise. Follow the
installation instructions on your screen.
Making a USB Recording
After installation, the software is configured to make a one-Mbyte snapshot
recording of your USB traffic.
To make this recording,
Step 1 Click on the Tool Bar.
After 1 Mbyte of traffic is recorded, the Analyzer uploads the data and
displays the packets.
To upload and display less than one Mbyte of traffic,
Step 2 Click on the Tool Bar at any time before recording automatically
terminates.
When the recording session is finished, the bus traffic is saved to the hard
drive as a file named data.usb or whatever name you assign as the
default filename.
To save a current recording for future reference,
Step 3 Select Save As under File on the Menu Bar.
OR
Click on the Tool Bar.
You see the standard Save As screen.
Step 4 Give the recording a unique name and save it to the appropriate directory.
