121
Chief User’s Manual CATC Version 1.7
• Uploading
After recording stops, the following occurs:
• The flashing message changes to Uploading data–x% done (x% indicates the
percentage completion of the data uploading process).
• The traffic data is copied to disk (overwriting any previous version of this file)
using the default file name data.usb or a new name specified in the Recording
options.
To abort the upload process, press Esc on your keyboard.
OR
Again click in the Tool Bar.
You are prompted to choose whether to keep the partially uploaded data or to
throw it away.
When the data have been saved, the Recorded Data file appears in the main
display window and the Recording Status window is cleared.
• If the recording resulted from a Trigger Event, the first packet following the
Trigger (or the packet that caused the Trigger) is initially positioned second
from the top of the display.
• If the recording did not result from a Trigger Event, the display begins with the
first packet in the traffic file.
Recording Activity
During recording, the third segment of the Status Bar displays
• The current recording speed: FS (full-speed) or LS (low-speed).
• Recording activity.
The larger the number of vertical bars displayed, the greater the amount of activity
being recorded. If there are no vertical bars, there is no recorded activity.
During uploading, this segment displays the percent of the upload process
completed.
Note If packets are filtered from the recording or data are truncated, the recording
activity is reduced.
Search Status
The rightmost segment displays the current search direction: Fwd (forward) or
Bwd (backward).
Zoom In
Zoom In increases the size of the displayed elements, allowing fewer (but larger)
packet fields per screen.
