107
Chief User’s Manual CATC Version 1.7
Secondary Recording Main Display Window
When configured for secondary recording, the USB Chief program’s main display
includes additional or modified items under the pull-down menus.
Table 4: Secondary Recording Pull-Down Menus
In addition, several of the standard Analyzer functions are modified to account for
the presence of data recorded on the Secondary channel.
Secondary Recording File Options
Save As
When the BusEngine is configured for Secondary Channel Recording, you can
indicate whether the first and last packets were recorded from the Primary or the
Secondary channel while you are saving a packet range.
Menu Function
File
Export » Export Packets to text (Packet View Format only)
Search
Search In Toggles the search between the Primary and Secondary channels.
View
Hide Primary Removes packets recorded on the Primary channel from the display
Hide Secondary Removes packets recorded on the Secondary channel from the display
