92
Chief User’s Manual CATC Version 1.7
Timing and Bus Usage Calculator
From the Report menu, select Timing Calculations.
OR
Click in the Tool Bar.
The Timing and Bus Usage Calculator appears.
Use the Timing and Bus Usage Calculator to set options for Bus Utilization, Time
Usage, Bandwidth, and Advanced Filtering.
Transaction Summary
Step 1 From the Report menu, select Transaction Summary.
(There is no corresponding button on the Tool Bar for this feature.)
Step 2 In the Transaction Report window, enter the values in the From Packet
and To Packet fields.
Step 3 Click OK.
