102
Chief User’s Manual CATC Version 1.7
• In the upper left hand corner is a traffic light bit map.
As the traffic is transmitted on the USB, the blue bar indicates in white progress
for overall traffic.
Start Traffic Generation
To instruct the USB Chief Plus Analyzer to begin generating traffic,
Step 1 Open a Traffic Generation file.
Step 2 From the Generate menu, select Start Traffic.
OR
Click on the Tool Bar.
The Analyzer downloads the generation stream to the unit and then begins
transmitting on the USB. Traffic is generated on the primary Record & Generate
port sequentially as defined in the traffic generation view. If your Generator Text
File is large or has lengthy bus conditions, a progress bar displays the status of the
download. When the generation reaches the end of the view, the traffic stops.
Repeat Mode
To instruct the Analyzer to continue to generate traffic until you stop it manually,
• Select Repeat Mode under Generate on the Menu Bar
OR
Click on the Tool Bar.
Stop Traffic Generation
To instruct the Analyzer to halt traffic generation,
• Select Stop Traffic under Generate on the Menu Bar
OR
Click on the Tool Bar.
Examples of *.utg files are included with the software and are located in the
installation directory.
