Software Installation and Configuration
2
L4400 User’s Guide
41
Click ‘Next’ until the window shown in Figure 2-22 appears.
Figure 2-22. Firmware Update Utility Firmware File Selection.
2. Using the ‘Browse’ button, specify the path to the firmware file and
then click ‘Next’.
The ‘Applicable Model’ window lists the L4400 series instruments
which are updateable by the current firmware (.xs) image. The window
is NOTused to select the instrument receiving the firmware update.
Firmware updates are performed on one instrument at a time. Once the
firmware update is complete, you must exit and re-start the utility to
update each instrument.
N O T E
