L4445A Microwave Switch/Attenuator Driver 7
L4400 User’s Guide 169
Y1153A
The Y1153A supports the attenuators listed below. Up to two of the
attenuators may be connected.

Y1153A Attenuator Options Supported
(Recommended options are shaded).
84904/5/6/7/8
Agilent
Attenuator Description
84904K/L 11 dB max, 1 dB steps, 4 sections
84906K/L 90 dB max, 10 dB steps, 4 sections
84907K/L 70 dB max, 10 dB steps, 3 sections
84904M 11 dB max, 1 dB steps, 4 sections
84905M 60 dB max, 10 dB steps, 3 sections
84908M 65 dB max, 5 dB steps, 4 sections
8494G/H 11 dB max, 1 dB steps, 4 sections
8495G/H 70 dB max, 10 dB steps, 3 sections
8496G/H 110 dB max, 10 dB steps, 4 sections
Option Name Option Number Description and Comments
Frequency Range letter suffix in
model number All options supported
RF Connectors various All options supported
Coil Voltage 011 +5VDC
015 +15VDC
024 +24VDC (required if using internal power)
DC Connector Type STD 10 pin ribbon cable header
Calibration
Certificate UK6 All options supported
