Agilent Technologies L4400 User Manual
Page 37
Click either to
test connection
Note serial number to identify
multiple instruments
Software Installation and Configuration
2
L4400 User’s Guide
25
Figure 2-9. Verifying a Communication Path to the Instrument.
The LAN Instrument window identifies the instrument’s host name, its IP
address, its VISA address, and product number. Because the network
server used in this example does not support Dynamic DNS, the host
name is not registered for use by the server. Thus, the instrument is
accessed by its IP address.
Click on “Test Connection” or “Identify Instrument” to test the communi-
cation path to the instrument. Click on”OK” to add the configured instru-
ment to your network.
Repeat the sequence of Figures 2- 7 through 2- 9 for each instrument. As
instruments are added, they appear in the Agilent Connection Expert
Explorer pane as shown in Figure 2- 10. Selecting the instrument in the
Explorer pane displays its properties in the Properties pane.
