136

L4400 User’s Guide

7

L4445A Microwave Switch/Attenuator Driver

L4445A SCPI Command Summary

Table 7- 1 lists the instrument- specific SCPI commands that apply to the
L4445A Microwave Switch / Attenuator Driver Instrument. Table 3- 3
(Chapter 3) lists the SCPI commands that apply to all L4400 series
instruments.

For complete information on all SCPI commands, refer to the
Programmer’s Reference contained on the L4400 Product Reference
CD- ROM (p/n 34989- 13601).

Table 7-1. L4445A SCPI Command Summary.

Subsystem

Commands

ROUTe

(Switch Control)

ROUTe:CHANnel:DRIVe:CLOSe:DEFault (@)
ROUTe:CHANnel:DRIVe:CLOSe:DEFault? (@)
ROUTe:CHANnel:DRIVe:OPEN:DEFault (@)
ROUTe:CHANnel:DRIVe:OPEN:DEFault? (@)
ROUTe:CHANnel:DRIVe:PAIRed[:MODE] {OFF|0|ON|1},
(@)
ROUTe:CHANnel:DRIVe:PAIRed[:MODE]? (@)
ROUTe:CHANnel:DRIVe:PULSe[:MODE] {OFF|0|ON|1}, (@)
ROUTe:CHANnel:DRIVe:PULSe[:MODE]? (@)
ROUTe:CHANnel:DRIVe:PULSe:WIDTh {|MIN|MAX|DEF},
(@)
ROUTe:CHANnel:DRIVe:PULSe:WIDTh? [{MIN|MAX}, ] (@)
ROUTe:CHANnel:DRIVe:STATe? (@)
ROUTe:CHANnel:DRIVe:TIME:RECovery {
|MIN|MAX|DEF}, (@)
ROUTe:CHANnel:DRIVe:TIME:RECovery? [{MIN|MAX}, ]
(@)
ROUTe:CHANnel:DRIVe:TIME:SETTle {|MIN|MAX|DEF},
(@)
ROUTe:CHANnel:DRIVe:TIME:SETTle? [{MIN|MAX}, ] (@)
ROUTe:CHANnel:LABel:CLEar:MODule 1
ROUTe:CHANnel:LABel[:DEFine] "
