164 L4400 User’s Guide
7 L4445A Microwave Switch/Attenuator Driver
Y1152A
The Y1152A supports one of the 87xxx switches and up to two of the
Agilent N181x switches. Supported switches are shown below.

Y1152A Switch Options Supported
(Recommended options are shaded).

Agilent Switch Description
87204A/B/C SP4T 4 port latching
87206A/B/C SP6T 6 port latching
87606B 6 port matrix
N1810UL Unterminated latching 3-port (SPDT)
N1810TL Terminated latching 3-port (SPDT)
N1811TL Terminated latching 4-port (transfer)
N1812UL Unterminated latching 5-port
Option Name Option Number Description and Comments
Frequency Range letter suffix in
model number All options supported
Coil Voltage STD (no options) +24VDC nominal (+20VDC to +32VDC
allowed)
DC Connector Type STD 16 pin ribbon cable header
100 Solder lugs

Can use ribbon cables with the Y1152A, or
discrete wires with the Y1155A.
Calibration
certificate UK6, UKS All options supported
Drive Options STD Direct coil connections for open collector drive
