154
L4400 User’s Guide
7
L4445A Microwave Switch/Attenuator Driver
This command uses special channel addressing as described in
This command requires the channel drive source be in order to allow
execution (
ROUTe:RMODule:DRIVe:SOURce OFF
).
Distribution Boards
Each 34945EXT remote module can hold up to four distribution boards.
Distribution boards are designed to support the most common types of
Agilent microwave switches and attenuators. The table below shows the
distribution boards available and lists the supported switches and
attenuators.
Specific information for each distribution board and the supported switch
types is given in the following sections.
Distribution boards are specialized terminal boards and hold no active
electronic components. The distribution boards can be identified by the
system (refer to the
SYSTem:CTYPe:RMODule?
and
SYSTem:CDEScription:RMODule?
commands description in the
Programmers Reference Help file).
Channel drive attributes for each distribution board will be set to the
values shown on
ROUT:RMOD:BANK:LED:DRIV
ON
ON
ON
ON
ON
ON
ROUT:RMOD:BANK:LED:LEV
0.005 A
0.005 A
0.005 A
0.005 A
0.005 A
0.005 A
ROUT:CHAN:DRIV:CLOS:DEF
OFF
OFF (except
channel 7, 17)
ON
OFF
OFF
OFF
ROUT:CHAN:DRIV:OPEN:DEF
ON
ON (except
channel 7, 17)
OFF
ON
ON
ON
Y1150A
Distribution board for up to eight N181x SPDT switches
(9-pin Dsub connectors)
Y1151A
Distribution board for two 87104x/106x multiport or
87406B matrix switches
Y1152A
Distribution board for a single 87204x/206x or
87606B switches and two N181x SPDTswitches
Y1153A
Distribution board for two 84904/5/8x or
8494/5/6 step attenuators
Y1154A
Distribution board for two 87222 transfer switches and
up to six N181x SPDT switches
Y1155A
Distribution board with screw terminals for up to 16 switch drives
