162 L4400 User’s Guide
7 L4445A Microwave Switch/Attenuator Driver
Y1151A Switch Control
All channels are single drive.
Path Closed Path Open
SW1 Path 1 ROUT:CLOS (@xx01) Close another path or open all
SW1 Path 2 ROUT:CLOS (@xx02) Close another path or open all
SW1 Path 3 ROUT:CLOS (@xx03) Close another path or open all
SW1 Path 4 ROUT:CLOS (@xx04) Close another path or open all
SW1 Path 5 ROUT:CLOS (@xx05) Close another path or open all
SW1 Path 6 ROUT:CLOS (@xx06) Close another path or open all
SW1 Open All 1 ROUT:CLOS (@xx07)
SW2 Open All 1 ROUT:CLOS (@xx08)
Path Closed Path Open
SW2 Path 1 ROUT:CLOS (@xx11) Close another path or open all
SW2 Path 2 ROUT:CLOS (@xx12) Close another path or open all
SW2 Path 3 ROUT:CLOS (@xx13) Close another path or open all
SW2Path 4 ROUT:CLOS (@xx14) Close another path or open all
SW2 Path 5 ROUT:CLOS (@xx15) Close another path or open all
SW2 Path 6 ROUT:CLOS (@xx16) Close another path or open all
SW2 Open All 2 ROUT:CLOS (@xx17)
SW2 Open All 2 ROUT:CLOS (@xx18)
