152 L4400 User’s Guide
7 L4445A Microwave Switch/Attenuator Driver
Default and Reset States
The L4445A allows several types of reset and default actions. Most resets
rely on states stored in non- volatile memory on the remote modules.
Default parameters can be set to ensure the system always returns to a
safe state.
SYSTem:RMODule:RESet
This command is the only command that will reset all remote modules
connected to the L4445A to the factory defaults. No determination of the
distribution boards present is made. The system is set to the following
conditions after executing this command.

ROUTe:RMODule:DRIVe:SOURce:IMMedia
te OFF
ROUTe:RMODule:DRIVe:SOURce:BOOT OFF
ROUTe:RMODule:DRIVe:LIMit 1
ROUTe:RMODule:BANK:DRIVe:MODE OCOLlector
ROUTe:RMODule:BANK:LED:DRIVe:ENA
Ble ON
ROUTe:RMODule:BANK:LED:DRIVe:LEVe
l 5 mA
ROUTe:CHANnel:DRIVe:PAIRed:MODE OFF
ROUTe:CHANnel:DRIVe:PULSe:MODE ON
ROUTe:CHANnel:DRIVe:PULSe:WIDTh 15 ms
ROUTe:CHANnel:DRIVe:TIME:RECovery 0.0 seconds
ROUTe:CHANnel:DRIVe:TIME:SETTle 0.0 seconds
ROUTe:CHANnel:DRIVe:OPEN:DEFault OPEN selected
ROUTe:CHANnel:VERify:ENABle OFF
ROUTe:CHANnel:VERify:POLarity NORMal
