The line between external Trigger Out and external Trigger In is
shared. You can use the external Trigger Out to provide the
external Trigger In signal. However, both a user-supplied external
trigger and the L4451A Trigger Out cannot drive the line at the
same time.
226 L4400 User’s Guide
9 L4451A 4-Channel Isolated D/A Converter with Waveform Memory
L4451A SCPI Command Summary
Table 9- 1 lists the instrument- specific SCPI commands that apply to the
L4451A 4- Channel Isolated D/A Converter instrument. Table 3- 3
(Chapter 3) lists the SCPI commands that apply to all L4400 series
instruments.
For complete information on all SCPI commands, refer to the
Programmer’s Reference contained on the L4400 Product Reference
CD- ROM (p/n 34989- 13601).
Table 9-1. L4451A SCPI Command Summary.
N O T E
Subsystem Commands
SOURce
(DAC
Configuration)
(Trace
Waveform
Configuration)
SOURce:CURRent[:LEVel] {|MIN|MAX|DEF}, (@)
SOURce:CURRent[:LEVel]? [{MIN|MAX}, ] (@)
SOURce:FUNCtion:TRIGger:SOURce {IMMediate|MANual|EXTernal},
(@)
SOURce:FUNCtion:TRIGger:SOURce? (@)
SOURce:MODE {VOLTage|CURRent}, (@)
SOURce:MODE? (@)
SOURce:MODule:CLOCk:FREQuency {|MIN|MAX|DEF}, 1
SOURce:MODule:CLOCk:FREQuency? [{MIN|MAX}, ] 1
SOURce:MODule:CLOCk:STATe {OFF|0|ON|1}, 1
SOURce:MODule:CLOCk:STATe? 1
SOURce:MODule:TRIGger:EXTernal:IMMediate 1
SOURce:MODule:TRIGger:OUTPut {OFF|0|ON|1}, 1
SOURce:MODule:TRIGger:OUTPut? 1
SOURce:VOLTage[:LEVel] {|MIN|MAX|DEF}, (@)
SOURce:VOLTage[:LEVel]? [{MIN|MAX}, ] (@)
SOURce:FUNCtion:CLOCk:EXTernal:DIVisor {|MIN|MAX|DEF},
(@)
SOURce:FUNCtion:CLOCk:EXTernal:DIVisor? [{MIN|MAX}, ] (@)
SOURce:FUNCtion:CLOCk:SOURce {INTernal|EXTernal|STEP}, (@)
SOURce:FUNCtion:CLOCk:SOURce? (@)
SOURce:FUNCtion:CURRent:GAIN {|MIN|MAX|DEF}, (@)
SOURce:FUNCtion:CURRent:GAIN? [{MIN|MAX}, ] (@)
