L4445A Microwave Switch/Attenuator Driver
7
L4400 User’s Guide
179
Y1155A
The Y1155A provides screw terminal connections can support the Agilent
switches listed below. Additionally, the screw terminals make it adaptable
to most any switch.
When using the Y1155A, the
ROUTe:RMODule:BANK:PRESet
command’s default configuration (see
) may not be suitable for
the wide variety of switches and devices available. You will need to
manually configure the channel drive attributes to ensure safe reset
operations of these switch systems.
Agilent Switch
Description
8762A/B/C
Terminated latching 3-port (SPDT)
8762F
75 ohm terminated SPDT
8763A/B/C
Terminated latching 4-port (transfer)
8764A/B/C
Terminated latching 5-port
Other Switches
Numerous
N O T E
