Avaya G350 Manager User Guide 85
WAN Configuration
To view the Serial Port tab of the USP Configuration dialog box, click the
USP symbol in the Chassis View or the Tree View. The USP Configuration
dialog box opens displaying the Serial Port tab.
Figure 7-15. USP Dialog Box - Serial Port Tab
The USP Configuration dialog box provides configuration and status
information about the USP.
The following table lists the configuration fields in the Serial Port tab of
the USP Configuration dialog box and their descriptions:
Table 7-8. USP Dialog Box - Serial Port Parameters
Field Description
Description The USP port description.
Port Type The type of port - Universal Serial Port.
Port Functionality The functionality of the port. Possible values
include:
• V.35 DTE
• X.21 DTE
• EIA530A DTE
