Chapter 7
66 Avaya G350 Manager User Guide
Channel Group - Frame Relay Information
The Channel Group dialog box for Channel Groups using frame relay
contains five tabs:
• Channel Group - Basic information about the Channel Group.
For information on the fields in the Channel Group tab of the
Channel Group - Frame Relay dialog box, refer to
“Channel
Group” on page 60 .
• Advanced - Information about the channels that comprise the
Channel Group. For information on the fields in the Advanced tab
of the Channel Group - Frame Relay dialog box, refer to
“Advanced” on page 62 .
• Frame Relay - Information about frame relay on the Channel
Group.
• Sub-Interfaces - Information about the Channel Group’s sub-
frame relays.
• DLCIs - DLCI information for the Channel Group.
Frame Relay
The Frame Relay tab of the Channel Group dialog box provides
information about the frame relay configuration of the Channel Group.
To view the Frame Relay tab of the Channel Group dialog box:
1. Click a Channel Group icon in the Chassis View. A list of Channel
Groups on the port appears.
2. Click the Channel Group you want to configure. The Channel
Group dialog box opens with the Channel Group tab.
