Avaya G350 Manager User Guide 71
WAN Configuration
To modify the parameters of a Sub-Frame-Relay interface:
1. Click the Sub-Frame-Relay interface you want to modify. The
configuration parameters of the selected Sub-Frame-Relay
interface appear in the bottom of the dialog box.
2. Modify the parameters you want to change using the fields at the
bottom of the dialog box.
3. Click Apply . The Sub-Frame-Relay interface parameters are
modified.
To delete a Sub-Frame-Relay interface:
1. Click the Sub-Frame-Relay interface you want to delete.
* Note: You can only delete Sub-Frame-Relay interfaces on which no
IP interfaces are defined.
2. Click Delete .
3. Click Apply . The Sub-Frame-Relay interface is deleted.
The following table provides a list of the fields in the Sub-Frame-Relay
interfaces tab of the Channel Group dialog box and their descriptions:
Table 7-5. Channel Group Dialog Box -
Sub-Interfaces Parameters
Field Description
Name The name of the interface.
Description A user defined description of the
Sub-Frame-Relay.
Type The type of Sub-Frame-Relay interface.
Currently, only Point to Point interfaces are
supported.
Bandwidth (kb/s) The bandwidth of the Sub-Frame-Relay
interface in bits per second.
Administrative Status The administrative status of the interface.
Possible statuses include:
• Enable
• Disable
