Avaya G350 Manager User Guide 43
Media Gateway Functions
MGC Config
The MGC Config tab provides information about the Media Gateway
Controller’s settings, IP address, and registration information.
Figure 5-2. MGC Config Tab
The MGC registers with the Media Gateway, after which it receives its IP
address from the Media Gateway. After you register, the Link Status will
be
Up, and an IP address will appear.
802 Priority Priority based on the 802.1p standard, which
assigns rights and privileges to users on a
telephony network. Possible values are 0 - 7.
Operational Status Operational Status of the Media Gateway.
Possible values are:
• OK - Media Gateway is operating
properly.
• Fatal - Media Gateway is down.
Fault Messages A list of fault messages.
Table 5-1. MG Config Parameters (Continued)
Field Description
