Chapter 16
166 Avaya G350 Manager User Guide
Routing Table
To display and update the Routing Table, select IP Route > Routing Table .
The Routing Table window opens.
Figure 16-3. Routing Table
The following parameters are displayed:
Table 16-3. Routing Table Parameters
Field Description
Destination The destination network IP address of this
route. An IP address of 0.0.0.0 denotes a default
router.
Netmask The destination network mask of this route.
IP Address The address of the next router of this route, via
which the destination of this route is reached.
Layer 2 Interface
Name The logical name of the local interface through
which the next hop of this route is reached.
Discard When this is checked, packets with a source IP
address of the next hop router are discarded.
