Avaya G350 Manager User Guide 129
Port Mirroring
Port Mirroring Wizard - VLAN Filtering
The VLAN Filtering screen of the Port Mirroring Wizard enables you to
filter the information copied to the destination port by VLAN number.
Figure 9-6. Port Mirroring Wizard - VLAN Filtering Screen
To configure which frames are copied to the destination port, select an
option from the
VLAN Filter pull-down list box. Possible options are:
• All VLANs - The destination port is configured with IEEE 801.Q
VLAN Tagging, and all information from the source port is copied
to the destination port.
• VLAN x - The destination port is configured with the selected
VLAN, and only packets tagged with that VLAN number are copied
to the destination port.
When you have finished selecting the traffic to be copied, click Next . The
Port Mirroring Wizard continues with the Port Mirroring Wizard -
Confirmation screen.
