Chapter 7
92 Avaya G350 Manager User Guide
USP - Frame Relay Interface
For USPs configured with a frame relay interface, the USP dialog box
contains five tabs:
• Serial Port - Basic information abut the USP. For information on
the fields in the Serial Port tab of the USP - Frame Relay dialog
box, refer to
“Serial Port” on page 84 .
• Advanced - Information about the channels that comprise the
interface. For information on the fields in the Advanced tab of the
USP - Frame Relay dialog box, refer to
“Advanced” on page 88 .
• Frame Relay - Information about the frame relay configuration
on the USP.
• Sub-Interfaces - Information about the Channel Group’s sub-
frame relays.
• DLCIs - DLCI information for the Channel Group.
IPCP Status IP Control Protocol. The state of IPCP for this
PPP session. IP packets can only be transmitted
and received over the PPP session when the
IPCP status is Open. Possible statuses include:
• Open
• Not-Opened
Table 7-10. USP Configuration - PPP Parameters (Continued)
Field Description
