Avaya G350 Manager User Guide 175
IP Route
You can modify RIP Global Parameters by checking boxes as desired.
RIP Interfaces
To define and display RIP interfaces, select IP Route > RIP > RIP Interfaces .
The RIP Interfaces window opens.
Figure 16-10. RIP Interfaces Window
The following parameters are displayed:
Redistribute OSPF
into RIP Controls redistribution of routes from OSPF to
RIP. If checked, all routes learned via OSPF are
advertised into RIP.
Redistribute Static
into RIP Controls redistribution of static routes into RIP.
If checked, the static routes inserted into the IP
Routing Table are advertised into RIP, according
to the "Leak Route" definition for each static
route.
Update Interval
(seconds) The amount of time between each RIP periodic
update.
Route Invalidate
Timeout (seconds) The amount of time after which a route
becomes invalid in the routing table.
Table 16-7. RIP Global Parameters (Continued)
Field Description
Table 16-8. RIP Interface Parameters
Field Description
Interface Name The name assigned to the selected IP interface.
