Chapter 3
32
Avaya G350 Manager User Guide
For more information on the user interface, refer to
.
STP Oper P2P
The operational point-to-point status of the
LAN segment attached to this port. It indicates
whether a port is considered to have a
point-to-point connection or not.
The value is determined by STP Admin P2P.
STP Admin Path Cost
The administratively assigned value for the
contribution of this port to the path cost of
paths towards the spanning tree root. A value
of 0 assigns the automatically calculated
default Path Cost value to the port.
STP Admin Path Cost complements STP Path
Cost, which returns the operational value of
the path cost.
STP Path Cost
The operational cost factor used by Spanning
Tree Protocol to determine the most efficient
route for forwarding traffic to its destination
while removing loops in the network.
For more information refer to Spanning Tree
Protocol (STA) in The Reference Guide.
STP Priority
The priority factor used by STP to determine
the activity status of an individual port on the
Spanning Tree.
STP Force Migration
When checked and in RSTP mode, the port is
forced to transmit RSTP BPDUs.
Port Classification
The classification of a specific port. Port
Classification allows network managers to
specify each port level’s importance. The
possible states are:
•
Regular
- Normal users.
•
Valuable
- Servers or critical users.
For more information refer to Port Classification
in The Reference Guide.
Table 3-4. Module Configuration Dialog Box (Continued)
Field
Description
