Avaya G350 Manager User Guide 69
WAN Configuration
Sub-
Interfaces
The Sub-Interfaces tab of the Channel Group dialog box provides
information about the configuration of Sub-Frame-Relay interfaces in the
Channel Group.
To view the Sub-Interfaces tab of the Channel Group dialog box:
1. Click a Channel Group icon in the Chassis View. A list of Channel
Groups on the port appears.
2. Click the Channel Group you want to configure. The Channel
Group dialog box opens with the Channel Group tab.
Backup Interface The interface’s backup status. Possible statuses
include:
• Backup By - Interface x - The selected
interface is backed up by interface x.
• Backup Of - Interface x - The selected
interface is the backup interface for
interface x.
• N/A - The selected interface is not
participating in a backup scheme.
Table 7-4. Channel Group Dialog Box -
Frame Relay Parameters (Continued)
Field Description
