Avaya G350 Manager User Guide 59
WAN Configuration
Viewing Channel Group Information
The Channel Group dialog box contains information specific to a selected
Channel Group. The tabs that appear in the Channel Group dialog box are
dependant on the encapsulation method of the selected Channel Group.
To view the Channel Group dialog box for a specific Channel Group:
1. Click a Channel Group symbol in the Chassis View. A list of
Channel Groups appears.
2. Click the Channel Group for which you want to view information.
The Channel Group dialog box for the selected Channel Group
opens.
* Note: Clicking New opens the Channel Group wizard, enabling
creation of a new Channel Group on the selected port. For
information about the Channel Group Wizard, refer to
“The
Channel Group Wizard” on page 78 .
Channel Group - PPP Session Information
The Channel Group dialog box for Channel Groups using PPP Sessions
contains three tabs:
• Channel Group - Basic information about the Channel Group.
• Advanced - Information about the channels that comprise the
Channel Group.
• PPP - Information about PPP on the Channel Group.
Loopback Status The type of loopback currently used by the port.
Possible values are:
• Near End Payload
• Near End Line
• Near End Inward
• Far End Payload
• Far End Line
Fault Messages Any faults that occurred on the port.
Table 7-1. E1/T1 Port Configuration Parameters (Continued)
Field Description
