Avaya G350 Manager User Guide 93
WAN Configuration
Frame Relay
The Frame Relay tab of the USP dialog box provides information about
the frame relay configuration of the USP.
To view the Frame Relay tab of the USP dialog box:
1. Click a USP symbol in the Chassis View or Tree View. The USP
dialog box opens with the Serial Port tab.
2. Click Frame Relay . The Frame Relay tab of the USP dialog box
appears.
Figure 7-18. USP Dialog Box - Frame Relay Tab
The following table provides a list of the fields in the Frame Relay tab of
the USP dialog box and their descriptions:
Table 7-11. USP Dialog Box - Frame Relay Parameters
Field Description
LMI Type Local Management Interface Type. The Data
Link Connection Management scheme used
by the frame relay interface. Possible values
are:
• ANSI
• q933a
• lmi-rev1
