Chapter 7
76 Avaya G350 Manager User Guide
Viewing the Channel Groups Table
To view the Channel Groups table, select Configure > WAN > Channel
Groups . The Channel Groups dialog box opens.
Figure 7-9. Channel Groups Dialog Box
Each row of the Channel Groups table represents a valid Channel Group.
The following table provides a list of the fields in the Channel Groups
table and their descriptions:
Table 7-7. Channel Groups Table Parameters
Field Description
Module Number The module that the Channel Group resides
on.
Channel-Group The name of the Channel Group.
Bandwidth The bandwidth of the Channel Group.
Encapsulation The Channel Group’s encapsulation. Possible
values are:
• PPPSession
• FrameRelay
