Avaya Media Gateway G350 - Manual (Page 194)

Chapter 16
184 Avaya G350 Manager User Guide
OSPF Link State Database
To display the OSPF Link State Database, select IP Route > OSPF >
OSPF Link State Database . The OSPF Link State Database window opens.
Figure 16-14. OSPF Link State Database Window
The following parameters are displayed:
Table 16-12. OSPF Link State Database Window
Field Description
LSA Type The type and format of the link state
advertisement; for example, Router links and
Network links.
LSA ID Identifies the part of the routing domain that is
described by the advertisement. The LSA ID can
be either a router ID or an IP address.
Router ID Identifies the originating router in the
autonomous system.
Sequence No. The sequence number of the link state
advertisement. Use this parameter to detect old
and duplicate link state advertisements. The
larger the sequence number, the more recent
the advertisement. Note that the sequence
number is usually negative.
