Avaya G350 Manager User Guide 97
WAN Configuration
2. Enter the parameters for the Sub-Frame-Relay interface using the
fields at the bottom of the dialog box.
3. Click Apply . The Sub-Frame-Relay interface is created.
To modify the parameters of a Sub-Frame-Relay interface:
1. Click the Sub-Frame-Relay interface you want to modify. The
configuration parameters of the selected Sub-Frame-Relay
interface appear in the bottom of the dialog box.
2. Modify the parameters you want to change using the fields at the
bottom of the dialog box.
3. Click Apply . The Sub-Frame-Relay interface parameters are
modified.
To delete a Sub-Frame-Relay interface:
1. Click the Sub-Frame-Relay interface you want to delete.
* Note: You can only delete Sub-Frame-Relay interfaces on which no
IP interfaces are defined.
2. Click Delete . A confirmation dialog box opens.
3. Click Yes .
4. Click Apply . The Sub-Frame-Relay interface is deleted.
The following table provides a list of the fields in the Sub-Interfaces tab of
the USP dialog box and their descriptions:
Table 7-12. USP Dialog Box - Sub-Frame-Relays Parameters
Field Description
Name The name of the Sub-Frame-Relay interface.
Description A user defined description of the
Sub-Frame-Relay.
Type The provisioning of the Sub-Frame-Relay
interface. Possible values are:
• Point to point
• Point to multipoint
Bandwidth The bandwidth of the Sub-Frame-Relay
interface in bits per second.
