Chapter 3
30 Avaya G350 Manager User Guide
Port Configuration - Advanced Tab
To view the Advanced tab of the Port Configuration dialog box for a
selected port:
1. Click the port symbol in the Chassis View.
Or
Click the port’s icon in the Tree View. The Port Configuration
dialog box opens to the General tab.
2. Click Advanced . The Advanced tab of the Port Configuration dialog
box appears.
Figure 3-4. Port Configuration Dialog Box - Advanced Tab
.
Table 3-4. Module Configuration Dialog Box
Field Description
Port STP Mode Configured status of Spanning Tree. Possible
values are:
• Enable
• Disable
