Chapter 7
98 Avaya G350 Manager User Guide
DLCIs
The DLCIs tab of the USP dialog box provides information about the
DLCIs in the USP.
To view the DLCIs tab of the USP dialog box:
1. Click a USP symbol in the Chassis View or Tree View. The USP
dialog box opens with the Serial Port tab.
Admin Status The administrative status of the Sub-Frame-
Relay interface. Possible values are:
• Enabled
• Disabled
Oper Status The operational status of the
Sub-Frame-Relay interface.
• Up - The interface is up and can transmit
and receive packets.
• Down - The interface is down due to
some failure, and cannot transmit or
receive packets.
• Testing - The interface is in testing mode
and cannot transmit or receive regular
data.
• Standby - The interface is a backup
interface and cannot transmit or receive
packets unless the primary interface it
backs up fails.
• Disabled - The interface is disabled. It
cannot transmit or receive packets.
• Partially Down - The interface is up.
However, some interfaces (or PVCs)
layered on top of this interface are Down.
Some packets can be transmitted and
received.
DLCIs A list of all DLCIs associated with the
Sub-Frame-Relay interface.
Table 7-12. USP Dialog Box - Sub-Frame-Relays Parameters
Field Description
