Avaya G350 Manager User Guide 75
WAN Configuration
To configure the priority of DLCI traffic, select the checkboxes for the
priorities to use on the DLCI.
If only one DLCI is configured for the Channel Group, all traffic uses the
DLCI.
If more than one DLCI is configured on the Channel Group, the priorities
must be distributed among the DLCIs, and no priority can be configured
on more than one DLCI. For example, if there are three DLCIs configured
for a Channel Group, the first DLCI may be configured with Primary and
High priority, the second with Medium and Normal, and the third with
Low.
Managing Channel Groups
The Channel Groups dialog box provides information about existing
channel groups and enables you to modify and delete channel groups. In
addition, you can start the Channel Group Wizard to create and edit
channel groups.
Primary When the Primary box is checked, the selected
DLCI is the primary carrier of traffic for the
interface.
Priorities Select the priority of traffic on the selected
DLCI from the available check boxes. Possible
priorities include:
• High
• Medium
• Normal
• Low
Table 7-6. Channel Group Dialog Box - DLCIs Parameters (Continued)
Field Description
