Offset 2 Offset for equation: REF R = R Gain X A/D# + R Off
Slope 2 Slope for equation: D/A# = current X Slope 2 + Off 2.
Corresponding to current or voltage output
Std. Density
Density of media (customer's original request) at standard conditions
usually at 14.7 PSIA and 70 degrees F: used by firmware for conversion
when a mass flow rate unit is chosen such as LB/HR etc.
Tot. Unit Unit of Totalizer as NCM or SCF
(Note that there is no time unit)
Prt B: Port B
Prt C: Port C
A/D Mode Analog to Digital Mode
B o x c a r A number between 1 - 64 that represents a signal filtering
parameter. See Chapter 3, Sample Rate
Link Mode Shows if link mode is enabled or disabled
Flow Min Minimum calibrated Flow Rate in SFPS
Flow Max Maximum calibrated Flow Rate in SFPS
dR Min dR value low end cutoff. Should be set to approximately
5 ohms less than the lowest dR corresponding to Flow Max
dR Max dR value high-end cut-off. Should be set to approximately
5 ohms greater than the dR corresponding to Flow Min
C1 - C5 Coefficients for Characteristic Equation; unique to each probe
CAL REF
Ω
Calibration Average Reference Resistance
T1 Temperature Compensation coefficients
T2 Serial number of unit
T3 Shop Order number of unit
T4 Engineering serial number - if any
Full Scale This is the value that the customer chooses to set
the 20mA (or 10 VDC) output to. The Max Flow value,
by comparison, is the highest flow, in SFPS, that the meter was
calibrated to. This value is in the customers units
Power Isolated Input AC power terminals are electrically isolated
from all other terminals
Turndown This is Full Scale divided by the Min Flow
Miscellaneous Terms
