Menu Window
The menu is made up of 4 components. They are the menu level, title, selections, and prompt
line. These components are illustrated in Figure 10. The top line displays a menu code and
title. Lines 2 and 3 are used to scroll through the available selections. The prompt line
indicates which menu commands are appropriate.
2.1 ANALOG SETUP
1=Setup Port 1
2=Setup Port 2
UP HOME
Menu
Level
Title
Available
Selections
Prompt
Line
C00435-1
The menu code is a numeric reference that identifies each window of the menu
structure. The menu code in Figure 10 indicates that the user is two levels deep
(Level 2, sublevel 1). The menu structure will be explained further in Menu
O r g a n i z a t i o n .
The title gives the user a better idea of where the system is within the menu structure. Some
titles are informative enough to completely describe the menu function, while other titles are
ambiguous unless there is knowledge of the parent menus.
The middle two lines display the available selection. The number of choices is often more than
the two displayed. Pressing the N (next) or P (previous) keys on the keypad will scroll the
selections up or down. To choose a function from the available selections press the
corresponding number on the keypad.
The prompt line displays appropriate menu control key strokes for that menu level. Pressing
N, the (N)ext key, will scroll the display down. Pressing P, the (P)rv or Previous key, will
scroll the display up. Pressing the UP key shifts the current menu level up one. Pressing the
HOME key goes straight to the 0.0 MAIN MENU.
Figure 10 - Menu Window
Other Window Types
Another common window encountered is shown in Figure 11. The window is similar to the
Menu Window except that it does not scroll and all choices are contained within the window.
The current selection (if there is one) is also contained in the parenthesis to the left of the
question mark.
Press the corresponding number in the Available Sections for the choice of display.
Figure 11 - Non-Scrolling Menu Window
3.1.2 STD VOLUME
1 = Cu feet
2 - Cu meter
3 = Liters
(CF)
s
?
Menu Level
Title
Current
Selection
Available
Selections
Prompt
Line
C00241-1
