The flowmeter has been configured and calibrated to custom specifications. Each flowmeter
contains distinct operating limits and units of measurement. This chapter will show how to
determine and manipulate the configuration of the flowmeter.
1. After the wiring has been verified, apply power to the flowmeter. (No special instructions
for instrument shutdown; turn operating power off.)
2. Then wait 10 minutes for warm-up. During this period the flowmeter may indicate high
flow.
3. After power up the instrument automatically enters the flow metering mode and the
display sets to normal operation.
Display
The flowmeter contains a 4 x 20 character LCD display. Flow rate, temperature, and system
status are all accessible through the display.
Initialization Window
When power is applied to the flowmeter the display will briefly show the initialization
window. See Figure 8.
Normal Mode Window
The flowmeter upon power up defaults to the normal mode of operation and begins to display
the flow rate, the temperature, the total flow (if enabled ) and the current system status. The
Normal Operation display is shown in Figure 9.
3. Operation
Introduction
Start Up Procedure
Operation
CH1: 5056.3 SCFM
CH2: 71.2 °F
435226 SCF
(grp1)(ed)(norm)(m)
Output
Channel #
Flow Rate
Temperature
Sample
Rate
Σ =
Mode Relay
Status Group #
Totalizer
C00239-2
Flow Units
Figure 9 - Normal Operation Display
Figure 8 - Initialization Window
FCI GF03
Initializing
Wait, Please
V1.00 Dec 16, 2003
Version Number and
Revision Date
C00549-1
