Function Desired * Keys to Press ** Comments
PORT 2: F.S.
Press HOME, 2, 1, 2, 3. Then
press in a numeric value. Then
press ENTR, 5, Y or N, HOME
Enter the numeric full-scale value
that is expected to occur. The value
needs to be between the values
shown on the second and third lines
of the display. Press ENTR without
inputting a numeric value only if
previous values are correct.
PORT 2: ZERO
Press HOME, 2, 1, 2, 4. Then
press in a numeric value. Then
press ENTR, 5, Y or N, HOME
Enter the numeric zero scale value
that is expected to occur. The value
needs to be between the values
shown on the second and third lines
of the display. Press ENTR without
inputting a numeric value only if
previous values are correct.
FLOW RATE UNITS
MASS UNITS
(1) LB (2) KG
(3) TNS
Press HOME, 3, 1, 1. Then 1 or 2
or 3, then in the TIME UNITS
menu press 1 or 2 or 3 or 4, then
in the AREA menu press 1 or 2,
then 1 or 2 or 3 or 4. The n enter a
numeric value. Press ENTR, any
key, any key, Y or N, HOME.
Enter the flow rate, using the
necessary mass units needed along
with the units per time and the pipe
diameter or area. ENTR can be
used if the values are already
correct.
Std Volume
(1) Cu Feet (2) Cu Meter
(3) Liters
Press HOME, 3, 1, 2. Then 1 or 2
or 3, then in the TIME UNITS
menu press 1 or 2 or 3 or 4, then
in the AREA menu press 1 or 2,
then 1 or 2 or 3 or 4. Then enter a
numeric value. Press ENTR, any
key, any key, Y or N, HOME.
Enter the standard volume in Cubic
Feet, Cubic Meters, or Liters along
with the units per time and the pipe
diameter or area. ENTR can be
used if the values are already
correct.
Std Velocity
Press HOME, 3, 1, 3. Then in the
LENGTH UNITS menu press 1
or 2. In the TIME UNITS menu
press 1 or 2 or 3 or 4, then any
key, Y or N, HOME.
Enter the standard velocity in feet
or meters per unit time.
SET PASSWORD
(1) Enable / Disable
Press HOME, 4, 3, 1 then HOME
The factory recommends the
password be enabled with this step
after the above information has
been completed.
* NUMBERS IN PARENTHESIS ARE KEYS TO BE PRESSED
** Y = SAVE PERMANENTLY OR N = DO NOT SAVE
Table 5 - Quick Operation Procedure
