Quick Operation Procedure
Input power is the only thing needed to operate the instrument. If a modification to the factory
setup is needed then continue with this section.
In order to use Table 5, an assumption has been made that the password is enabled (this is the
factory preset condition).
For proper operation of the flowmeter all the information in the Analog Output category needs
to be entered as a group, also all of the information in the Flow Rate Units category needs to
be entered (do not skip steps).
If mistakes in data entry are made, press the back arrow key to correct the mistake.
Table 5 - Quick Operation Procedure
Function Desired * Keys to Press ** Comments
Main Menu Press any key
To get from the normal display to the
main menu.
Main Menu Press OME THEN 1
To get from other menus to the main
menu in most cases. In some cases
(when shown) press ENTR. Then
HOME.
(1) NORMAL
OPERATION
Press HOME then 1 To get the normal display.
SET PASSWORD
(1) Enable / Disable
Press HOME, 4, 3, 1. Then
enter user password. Then press
ENTR, HOME
The factory recommends that the
password be disabled before any
information is entered to speed up the
process. (Default password: 123)
ANALOG OUTPUTS
PORT 1: MODE
(1) 4-20mA (2) 0-5V
(3) 1-10V (4) 1-5V Press HOME, 2, 1, 1, 1. Then 1
or 2 or 3 or 4 or ENTR. Then 5,
Y or N. HOME
Press the key that best matches the
analog input to the peripherals from
Jack JP6 of the Flow Transmitter. Press
ENTR only if previous values are
correct.
PORT 1: UNIT
(1) FLOW (2)
TEMP
Press HOME, 2, 1, 1, 2. Then 1
or 2. Then 5, Y or N, HOME Press the key that matches the
condition to be measured.
PORT 1: F.S.
Press HOME, 2, 1, 1, 3. Then
press in a numeric value. Then
press ENTR, 5, Y or N, HOME
Enter the numeric full-scale value that
is expected to occur. The value needs
to be between the values shown on the
second and third lines of the display.
Press ENTR without inputting a
numeric value only if previous values
are correct.
PORT 1: ZERO
Press HOME, 2, 1, 1, 4. Then
press in a numeric value. Then
press ENTR, 5, Y or N, HOME
Enter the numeric zero scale value that
is expected to occur. The value needs
to be between the values shown on the
second and third lines of the display.
Press ENTR without inputting a
numeric value only if previous values
are correct.
PORT 2: MODE
(1) 4-20mA (2) 0-5V
(3) 1-10V (4) 1-5V Press HOME, 2, 1, 2, 1. Then 1
or 2 or 3 or 4 or ENTR. Then 5,
Y or N. HOME
Press the key that best matches the
analog to the peripherals from Jack JP6
of the Flow Transmitter. Press ENTR
only if previous values are correct.
PORT 2: UNIT
(1) FLOW (2)
TEMP
Press HOME, 2, 1, 2, 2. Then 1
or 2. Then 5, Y or N, HOME Press the key that matches the
condition to be measured.
