Menu Control
The prompt line displays appropriate key strokes for that menu level. If a key is pressed that
is not valid for that menu, Invalid Response will flash briefly across the prompt line. The key
pad layout is shown in Figure 12.
1 2 3 Y N
4 5 6 _ .
7 8 9 P
ENTR 0 # HOME UP
C00220-1
Key Key Name Action
0 - 9 Numeric
Selects options and enters
numbers
Y Yes Enter a yes response
N No or (N)ext
Enter a no response or scrolls
to the next screen
- Minus Enter a minus sign
Decimal Point Enter a decimal point
Back Space Moves cursor back one space
P (P)rv or Previous Scrolls to the previous screen
ENTR Enter
Enters a numeric value or
response
HOME Home
Returns to the Main Menu or
escapes from routines
UP Up
Move current menu up one
level
Figure 12 - Key Pad
See Table 3 for key pad assignments. At any time, the HOME key can be pressed and the main
menu will display. HOME can be used to escape from most routines, restart a progression into
the menu structure, or quickly change from one area of the menu to another.
When (N)ext is displayed on the prompt line, more than two menu selections are available.
Press N to scroll through all the selections.
The UP key, will back-out of a menu level. The menu moves back one level each time the UP
key is pressed. The UP key only functions when UP is displayed on the prompt line.
To make a selection, press the numeric key associated with the desired menu selection. The
selection does not have to be displayed, but it must be one of the available selections.
Every path through the menu will eventually cause control to pass from the menu structure
to a routine that performs a task such as change a parameter value, initiate a test, or calibrate
the system hardware. When the system is operating outside the menu structure, there are
subtle differences in the user interface. For example, the UP key may have no affect or the
prompt line won't appear.
Table 3 - Key Assignments for the GF Series Key Pad
