Model GF03 Flow Meter 2 2 Doc. No. 06EN003352 Rev. B
w To choose a new unit of measure for total flow:
1. From the Main menu press 3. The 3.0 DISPLAY SETUP menu title will appear.
2. Press 3, the Totalizer Setup option.
3. Press 2, Flow Units, to change the units for total flow.
4. There is the option of standard volumetric units or mass units. See Table 6 for a
description of the available choices. Press 1 or 2.
5. After entering the user password (if it is enabled) the user will be prompted with
standard volumetric or mass units. Enter the desired total flow units.
6. The user will be prompted to enter the pipe cross-sectional area. The user has the
option of entering the area directly or, for circular pipes, entering the inside
diameter. Enter the method desired.
7. Enter the desired area units.
8. Enter the value of the pipe area or the pipe inside diameter. Press any key twice.
9. When prompted to Save permanently enter Y for yes.
w To choose Totalizer Prescaler for total flow:
1. From the Main menu press 3. The 3.0 DISPLAY SETUP menu title will appear.
2. Press 3, the Totalizer Setup option.
3. Press 7, Totalizer Prescaler, to change between prescale values of 0, .001 or 1000.
4. Press 0 for no prescale, or press 1 for a prescale value of .001, or press 2 for a prescale
value of 1000.
In this mode the totalizer will be displayed with a fixed decimal place.
w To choose Display Group Sum for total flow:
1. From the Main menu press 3. The 3.0 DISPLAY SETUP menu title will appear.
2. Press 3, the Totalizer Setup option.
3. Press 8, the Display Group Sum.
The totalized flow for the first group will be displayed. Pressing any key will display
the totalized flow for the second group if the second group is enabled. Pressing any
key will display the totalized flow for the third group if the third group is enabled.
The group totals will be displayed regardless if they have been initialized. These
values can be reset by switching to each group and individually resetting each one or
doing a reset all from menu 3.3.3.
w To choose Aggregate Tot Mode for total flow:
1. From the Main menu press 3. The 3.0 DISPLAY SETUP menu title will appear.
2. Press 3, the Totalizer Setup option.
3. Press 9, Aggregate Tot Mode, to turn on or off the aggregate total mode.
This setting is saved in EEPROM and recalled when the system is reset. When the
aggregate mode is enabled, the following parameters must be the same for all the
groups that are linked; totalizer prescale, and the totalizer units. If all the parameters
do not match, the totalizer display will show "AGGREGATE TOT ERROR".
